28527430 48V Jungheinrich Contactor

Used for:

ETM/V 14/16 10003296 5.95 - 4.99 1
ETM/V 20/ 25 / GN 10003299 5.96 - 3.99 1
ETM/V 10/12 10004069 10.97 - 3.99 1
ETM/V 110/112 10004663 4.99 - 12.05 1
ETM/V 214/216 10004665 5.99 - 11.03 1
ETM/V 220/320/325 10004666 4.99 - 3.00 1
ETM/V 114 50042569 4.99 - 12.05 1
ETM/V 220 50100351 4.00 - 10.04 1
ETM/V 320/325 50100352 4.00 - 11.04 1

Description:

50017080 Plate, Mounting  Electrics / 48V-DC
1 1    50016599 Plate, Mounting
10 1    50016683 Heatsink
11 2    50058837 Mikro pulse / MP1514
12 2    24203670 Screw
13 2    25600790 Lock washer
16 2    24203670 Screw
17 2    25600790 Lock washer
20 1    28525820 Holder, Fuse
21 2    ( 50 ) 24402250 Screw / M4X12
22 2    25601240 Lock washer
30 1    28431390 Board, Terminal
31 2    24402800 Screw
32 2    ( 50 ) 25601190 Lock washer / A5
40 1    28527430 Contactor
40.1 1    28527710 Kit, Contact
41 2    24004660 Screw
50 1    69437190 Fan / 48 V Air current in direction of arrow.
51 2    25000740 Self-tapping screw
60 1    50017082 Cable, Truck / 160A
61 2    24200710 Screw / M6x35
62 2    25600790 Lock washer
65 1    50017083 Cable, Power
70 1    28516750 Fuse / 355A/80V
71 2    ( 10 ) 25500170 Washer / D=10,5
72 2    ( 50 ) 25500900 Washer / 10,5
73 2    25600730 Lock washer
74 2    ( 50 ) 25301100 Nut / M10
80 1    50017406 Copper bridge
81 1    50017403 Copper bridge
82 1    50017524 Copper bridge
83 1    50017409 Copper bridge
84 1    50017405 Copper bridge
85 1    50017411 Copper bridge
86 1    43310630 Copper bridge
87 1    50017414 Copper bridge
88 1    50017415 Copper bridge
90 8    50146543 Screw / M8x16
91 8    ( 50 ) 25600850 Lock washer / B8
95 4    43573910 Clamp
96 6    ( 20 ) 25301090 Nut / M8
97 2    ( 50 ) 25600850 Lock washer / B8
101 2    ( 50 ) 24402420 Screw / M4X6
102 2    25601240 Lock washer
150 1    50015275 Interface board / MP1514C
151 1    50015791 Cable, Control Pos. without illustration.
151.200 1    28617530 Diode / 1N5408 Pos. without illustration.
151.400 1    50017273 Box, Fuse
151.401 1    26905110 Fuse
151.402 1    ( 5 ) 28528530 Fuse
151.403 2    26905130 Fuse / C 30A
151.404 2    28528360 Lead, Jumper
151.405 1    28528520 Fuse
151.500 2    50431303 Resistor / CAN BUS Pos. without illustration.
155 4    50008044 Spacer
156 4    50008042 Spacer
160 4    ( 20 ) 50430751 Tie, Cable / 3,5x150//3,6x140/sw Pos. without illustration.
170 1    ( 20 ) 24402860 Screw / M6x30
171 1    ( 50 ) 25601190 Lock washer / A5
172 1    50030543 Bonnet, El. system
998 1    50037469 Cable, Control Raise control. Only when using the mikropuls 1514 2U1 drive
-------------- control as raisecontrol:- establish X31.2 - X32.6 connection
-------------- using the control line pos.998) - see extract of wiring diagram;
-------------- whitout the control line(pos.998) there is no raise function!
